It’s a common idea among touring and off-road travellers: “If my 4WD and caravan share the same wheels and tyres, I’ll only need one type of spare.”

While the thought is appealing, the reality is far more complex. Between weight requirements, hub configurations, offsets, and tyre dynamics, it’s possible but a much more difficult process than can sometimes be worth. Below we’ll break down why.

🚫 Why Matching Isn’t a simple swap & go solution

• Swapping wheels and tyres between your 4WD and caravan isn’t always possible because each is engineered for different requirements. Caravans need wheels and tyres with higher static load ratings, specific stud patterns, and offsets designed for their axles and suspension. Even small differences in tyre size, hub fitment, or brake clearance can make wheels incompatible—and forcing a mismatch can compromise safety and performance.



⚖️ Wheel & Tyre Load Ratings

Load ratings are non-negotiable.

• Wheel Load Rating: This is the maximum static weight a wheel can support. Caravan wheels usually need a higher load rating than vehicle wheels because each axle carries more weight per wheel than on a tow vehicle. For example, a caravan with an ATM of 3,000kg on a tandem axle spreads 750kg per wheel. The chosen wheel must exceed that figure.

• Tyre Load Rating: Stamped on the tyre’s sidewall (e.g., “1150kg @ 65psi”), this is the maximum weight the tyre can handle at a given pressure. Tyres chosen for caravans must comfortably exceed the real-world load—ideally with a safety margin.

• The Catch: 4WD tyres are often designed for traction, speed ratings, and comfort. Caravan tyres are engineered for carrying heavy loads consistently. Matching them usually means compromising one or the other.

🔩 Stud Patterns & PCD

Even if the wheels “look” the same, subtle differences make interchangeability difficult.

• Stud Pattern: Refers to the number of wheel studs (bolts) and their arrangement. Common setups include 5-stud and 6-stud designs.

• PCD (Pitch Circle Diameter): This is the diameter of the circle that passes through the centre of all the studs. For example, a “6×139.7” means six studs arranged in a 139.7mm circle.

• The Problem: Your caravan might run a 6×139.7 pattern, while your 4WD has a 6×135. Even though they’re both “six-stud,” they are not interchangeable.

↔️ Offset (ET)

Offset is one of the most misunderstood elements in wheel compatibility.

• What is Offset? It’s the distance between the wheel’s mounting face and its centreline, measured in millimetres.

  • Positive offset: Mounting face sits closer to the outside of the wheel (common in modern 4WDs).

  • Negative offset: Mounting face sits further inside (common in caravans and older off-road wheels).

• Why it Matters: Incorrect offset changes where the load sits on wheel bearings and suspension. Too much positive offset can cause rubbing on brakes or control arms; too much negative offset increases stress on bearings and axles.

• Caravan Impact: Caravan hubs and stub axles are engineered with specific offsets in mind. Swapping to 4WD wheels with different offsets can lead to premature bearing or suspension failure.

📏 Tyre Size & Rolling Diameter

Tyres aren’t just about width and diameter—they directly affect handling and safety.

• Size Format Example: A 265/70R17 tyre has:

  • 265mm tread width

  • 70% aspect ratio (tyre height is 70% of width = 185.5mm)

  • Fits a 17-inch wheel

• Rolling Diameter: The total height of the tyre once fitted. If caravan tyres are significantly smaller or larger than your 4WD tyres, matching them introduces stability risks.

• Sidewall Stiffness: Caravan tyres are built with stiffer sidewalls to handle load and resist sway. 4WD tyres often prioritise off-road grip and flex. Swapping them undermines performance in both applications.

✅ The Better Approach

Instead of forcing your caravan to use your 4WD wheels and tyres:

• Carry dedicated spares—one for your 4WD and at least one for your caravan.

• Use tyres and wheels engineered specifically for caravan loads.

• Match tyre pressures and load ratings to the van’s ATM for stability and compliance.

• Focus on maintenance—checking pressures, bearings, and wear regularly.

• Carry a Tyre Puncture Repair Kit – this has been a simple solution for us when exploring remote Australia and provides a quick and simple repair, but is also easier to pack and saves weight.

🏕 Final Word

While matching your 4WD and caravan wheels may sound like the ultimate touring hack, it’s usually more trouble than it’s worth. Load ratings, stud patterns, offsets, and tyre designs are rarely aligned between vehicles and vans—and overlooking these differences can compromise safety.

The best solution? Use properly rated caravan wheels and tyres, carry the right spares, and keep both setups maintained for reliable, worry-free travel.
